ColourUrban Silver
CapacityLink aggregation ports: 8 - IPv4 routes (static): 32 - VLANs supported: 256 - Access Control Entries (ACEs) per ACL: 480 - Packet buffer size: 1.5 MB
Mac Address Table Size16000 entries
PerformanceSwitching capacity: 128 Gbps - Throughput: 95.23 Mpps - Latency (1 Gbps): 2.4 -s - Latency (10 Gbps): 1.3 -s
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Weight2.41 kg
Jumbo Frame Support9216 bytes
Enclosure TypeRack-mountable 1U
Routing ProtocolStatic IP routing
NetworkingSwitch
PowerAC 120-230 V (50-60 Hz)
Manufacturer WarrantyLimited lifetime warranty
Ports24 x 10-100-1000 + 4 x 1 Gigabit10 Gigabit SFP+
Depth22.15 cm
Dimension44.25 cm x 22.15 cm x 4.39 cm
Width44.25 cm
Remote Management ProtocolHTTP
SubtypeGigabit Ethernet
BrandHPE Aruba
Product TypeSwitches
