Specifications
General
Brand
HPE Aruba
Colour
Urban Silver
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af
Performance
Switching capacity: 128 Gbps - Throughput: 95.23 Mpps - Latency (1 Gbps): 2.4 -s - Latency (10 Gbps): 1.3 -s
Poe Budget
370 W
Product Type
Switches
Remote Management Protocol
HTTP
Routing Protocol
Static IP routing
Subtype
Gigabit Ethernet
Memory
Capacity
Link aggregation ports: 8 - IPv4 routes (static): 32 - VLANs supported: 256 - Access Control Entries (ACEs) per ACL: 480 - Packet buffer size: 1.5 MB
Jumbo Frame Support
9216 bytes
Display
Mac Address Table Size
16000 entries
Connectivity
Networking
Switch
Power Over Ethernet
PoE
Ports
Ports
24 x 10-100-1000 (PoE) + 4 x 1 Gigabit10 Gigabit SFP+
Power
Power
AC 120-230 V (50-60 Hz)
Physical
Dimension
44.25 cm x 26.47 cm x 4.39 cm
Weight
3.67 kg
Operating System
Enclosure Type
Rack-mountable 1U
