Capacity32 Gbps
Mac Address Table Size8192
Switching Capacity32 Gbps
AcousticsSound Power, LWAd - 0 Bel Sound Pressure, LpAm (Bystander) - 0 d
Operating Temperature32 F to 113 F (0 C to 45 C) up to 5000 ft (1.5 km) derate -1 C for every 1000 ft (305 m) from 5000 ft (1.5 km) to 10000 ft (3.0 km)
Weight2.78 kg
Poe Capability139W Class 4 PoE/PoE+
Poe PowerIdle- 16W Max Power (w-o PoE)- 21.9W Max Power (w- PoE)- 170W
Throughput23.8 Mpps
Country Of OriginChina
Differentiator12x ports 10/100/1000BASE-T Ports
2x 1G SFP ports
2x 1GbE ports
Supports PoE Standards IEEE 802.3af, 802.3at
1x USB-C Console Port
1x USB Type-A Host port
Memory 16 GB eMMC
Ports12x ports 10/100/1000BASE-T Ports 2x 1G SFP ports 2x 1GbE ports
Voltage100-127 VAC / 200-240 VAC
No Ofports12x ports 10-100-1000BASE-T Ports
WarrantyLimited lifetime warranty.
Dimension1.73 x 10.0 x 10.04
Latency Timing1 Gbps: 2.3 μSec
Throughput Mpps23.8 Mpps
Power ConsumptionMax Power (w/o PoE): 21.9W
Max Power (w/ PoE): 170W
BrandHPE Aruba
Product TypeSwitches
