CapacityAuthenticated users (internal database): 250, DPI connections: 500000, DPI SSL connections: 125000, IPSec VPN clients: 50, Maximum number of access points: 32, SPI connections: 1500000, SSL VPN licenses: 2, Virtual interfaces (VLANs): 256, VPN tunnels (site-to-site): 250
Data Link Protocol10 Gigabit Ethernet, Gigabit Ethernet
Encryption Algorithm128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, TLS 1.3, Triple DES
Compliant StandardsANATEL,BSMI,CB,Common Criteria,C-Tick,cUL,EMC,FCC Class A certified,FIPS 140-2 Level 2,ICSA Antivirus,ICSA Firewall certified,KCC Class A,LVD,Mexico CoC,MSIP Class A,REACH,RoHS,TUV GS,UC APL,UL,VCCI Class A,VPNC certified,WEEE
Operating Temperature104 degree Fahrenheit
Transport ProtocolDHCP, HTTP, HTTPs, ICMP/IP, IPSec, L2TP, PPPoE, PPTP, TCP/IP, UDP/I
Power Consumption Operational21.5 watt
Power Provided60 watt
Routing ProtocolBGP, OSPF, Policy-based routing (PBR), RIP-1, RIP-2, Static IP routing
Meta KeywordsSONICWALL NSa 2700
Country Of OriginTAIWAN
Interface1 x console - RJ-45, 1 x management - RJ-45, 16 x 1000Base-T - RJ-45, 2 x USB 3.0 - Type A, 3 x 10GBase-X - SFP+
Model NameSONICWALL NSa 2700
Power RedundancyOptional, Yes
Operating Relative Humidity5 - 95% (non-condensing)
Dimension16.9*12.8*1.8 inch
Inp VoltageAC 120/230 V
Frequency Range50/60 hertz
TypeInternal power supply
Rating Va WattsSonicOS 7.0
Remote Management ProtocolCLI, SNMP 2, SNMP 3, SSH
Voip ProtocolsH.323 v1, H.323 v2, H.323 v3, H.323 v4, H.323 v5, SIP
BrandSonicwall
Product TypeFirewall
